Passoni Top Evolution

Passoni

$8,199.00 USD

  • Passoni Top Evolution
  • Passoni Top Evolution
  • Passoni Top Evolution

This product is currently sold out.

Passoni Top Evolution - the traditional titanium road racer

Fully custom titanium frameset with matching full carbon fork
Matching kit with painted Cinelli bar + stem plus cages available - add $899
Matching Selle Italia saddle and leather bartape also available - add $399

Tubes: Titanium grade 9 (3Al/2,5V) with different thicknesses, drawn and strengthened. Titanium grade 5 (6Al/4V) for head tube, bottom bracket shell and dropouts, CNC machined
Front triangle: round tubes, top tube Ø 35 mm, seat tube Ø 35 mm, down tube Ø 37,3 mm
Rear triangle: round seat stays taper Ø 19 mm. Oval chain stays taper 31x20mm with loop for wiring output
Bottom bracket shell: titanium grade 5, CNC machined, Passoni engraved logo, BSA threading
Head tube: Ø 45 integrated, CNC machined, titanium grade 5, bearings 1"1/8
Dropouts: Passoni project, titanium grade 5, CNC machined, Ergal replaceable hanger
Seat post clamping device: bolt in titanium grade 5, with screw in titanium
Finishing / Graphics: tubes glazed by hand, graphics applied directly on the tube in titanium by sandblast
Colour Pure Titanium
Fork: Columbus Tusk Straight, customized Passoni
Other Components: Shimano Dura Ace 9000, Stem Cinelli Dinamo, Bar Cinelli Dinamo, Nokon Cables, Seat Post PMP Passoni, Selle Italia SLR Kit Carbon – Passoni Special Edition, Pedals Speedplay Zero Titanio, Lightweight Gipfelsturm, Veloflex Carbon
